1.3 Parameter Table
44 YASKAWA ELECTRIC TOEP C710687 03B FSDrive-MV1000 Parameter Guide
F4: Analog Monitor Card (AO-A3)
F4-01
(391H)
Analog Output 5
(Terminal V1)
Monitor Selection
Sets the monitor signal for output from analog output 5 (terminal V1). Set
this parameter to the last three digits (-) of the desired U-
monitor. Some U parameters are available only in certain control modes.
Default: 102
Min: 000
Max: 999
166
F4-02
(392H)
Analog Output 5
(Terminal V1) Gain
Sets the gain for voltage output via analog output 5 (terminal V1).
Default: 100.0%
Min: -999.9%
Max: 999.9%
166
F4-03
(3080H)
Analog Output 5
(terminal V1) Bias
Sets the amount of bias added to the voltage output via analog output 5
(terminal V1).
Default: 0.0%
Min: -999.9%
Max: 999.9%
166
F4-04
(3081H)
Analog Output 5
(Terminal V1) Cell
Selection
Sets the number of the power cell to be output from analog output 5
(terminal V1). This setting is effective when 9 (power cell) has been set
for F4-01 (Analog Output 5 (terminal V1) Monitor Selection).
Default: 1
Min: 1
Max: 15
166
F4-05
(3082H)
Analog Output 5
(Terminal V1)
Signal Level
Selection
Sets the signal level for analog output 5 (terminal V1).
0: 0 to 10 V
1: -10 to 10 V
Default: 1
Min: 0
Max: 1
167
F4-11
(3083H)
Analog Output 6
(Terminal V2)
Monitor Selection
Sets the monitor signal for output from analog output 6 (terminal V2). Set
this parameter to the last three digits (-) of the desired U-
monitor. Some U parameters are available only in certain control modes.
Default: 103
Min: 000
Max: 999
167
F4-12
(3084H)
Analog Output 6
(Terminal V2) Gain
Sets the gain for voltage output via analog output 6 (terminal V2).
Default: 100.0%
Min: -999.9%
Max: 999.9%
167
F4-13
(3085H)
Analog Output 6
(te
rminal V2) Bia
s
Sets the amount of bias added to the voltage output via analog output 6
(terminal V2).
Default: 0.0%
Min: -999.9%
Max: 999.9%
167
F4-14
(3086H)
Analog Output 6
(Terminal V2) Cell
Selection
Sets the number of the power cell to be output from analog output 6
(terminal V2). This setting is effective when 9 (power cell) has been set
for F4-11 (Analog Output 6 (Terminal V2) Monitor Selection).
Default: 1
Min: 1
Max: 15
167
F4-15
(3087H)
Analog Output 6
(Terminal V2)
Signal Level
Selection
Sets the signal level for analog output 6 (terminal V2).
0: 0 to 10 V
1: -10 to 10 V
Default: 1
Min: 0
Max: 1
168
No.
(Addr.)
Name Description Setting Page
All Modes
common_
All Modes
common_
All Modes
common_
All Modes
common_
All Modes
common_
All Modes
common_
All Modes
common_
All Modes
common_
All Modes
common_
All Modes
common_
