9.13 o: Keypad-Related Settings
644 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
â—† o2: Keypad Operation
No.
(Hex.)
Name Description
Default
(Range)
Ref.
o2-02
(0506)
OFF Key Function
Selection
Sets the function to use on the keypad to stop the drive when the Run command
source for the drive is REMOTE (external) and not assigned to the keypad.
0 : Disabled
1 : Enabled
1
(0, 1)
362
o2-03
(0507)
User Parameter Default
Value
Sets the function to keep the settings of changed parameters as user parameter defaults to
use during initialization.
0 : No change
1 : Set defaults
2 : Clear all
0
(0 - 2)
363
o2-04
(0508)
Drive Model (KVA)
Selection
Sets the Drive Model code. Set this parameter after you replace the control board. Determined by the drive
(-)
363
o2-05
(0509)
Home Mode Freq Ref
Entry Mode
Sets the function that makes it necessary to push to use the keypad to change the
frequency reference value while in Drive Mode.
0 : ENTER Key Required
1 : Immediate / MOP-style
0
(0, 1)
364
o2-06
(050A)
Keypad Disconnect
Detection
Sets the function that stops the drive if you disconnect the keypad connection cable from
the drive or if you damage the cable while the keypad is the Run command source.
0 : Disabled
1 : Enabled
1
(0, 1)
364
o2-09
(050D)
Reserved - - 364
o2-19
(061F)
Parameter Write during
Uv
Enables and disables the function to change parameter settings during a Uv [DC Bus
Undervoltage] condition.
0 : Disabled
1 : Enabled
0
(0, 1)
364
o2-24
(11FE)
LED Light Function
Selection
Sets the function to show the LED status rings and keypad LED lamps.
Note:
When you use A1-03 [Initialize Parameters] to initialize the drive, the drive will not
reset this parameter.
0 : Enable Status Ring & Keypad LED
1 : LED Status Ring Disable
2 : Keypad LED Light Disable
0
(0 - 2)
365
o2-27
(1565)
bCE Detection Selection Sets drive operation if the Bluetooth device is disconnected when you operate the drive in
Bluetooth Mode.
0 : Ramp to Stop
1 : Coast to Stop
2 : Fast Stop (Use C1-09)
3 : Alarm Only
4 : No Alarm Display
3
(0 - 4)
365
â—† o3: Copy Keypad Function
No.
(Hex.)
Name Description
Default
(Range)
Ref.
o3-01
(0515)
Copy Keypad Function
Selection
Sets the function that saves and copies drive parameters to a different drive with the
keypad.
0 : Copy Select
1 : Backup (drive → keypad)
2 : Restore (keypad → drive)
3 : Verify (check for mismatch)
4 : Erase (backup data of keypad)
0
(0 - 4)
365
o3-02
(0516)
Copy Allowed Selection Sets the copy function when o3-01 = 1 [Copy Keypad Function Selection = Backup (drive
→ keypad)].
0 : Disabled
1 : Enabled
0
(0, 1)
365
