YASKAWA iC9200 Series User Manual

HB700 | CPU | PMC921xEx | en | 24-04 77
iC9200 Series
Hardware description
Technical data > iC9212M-FSoE - PMC9212ES
Order no. PMC9212ES
CPU Triton (ARM A17)
CPU cores 3
Frequency 1.26 GHz
RAM 2 GB
eMMC 8 GB
Operating controls LEDs, Three-point switch, DIP-switches
Integrated SliceBus supply
ü
Connectors
Serial Com (Sub-D) -
SliceBus
ü
Number of RJ45 interfaces 4 Ports
External SD card
External SD card
ü
Operating system
Operating system Linux with RT Kernel
Overlay filesystem on internal eMMC
ü
Overlay filesystem on internal eMMC, Capacity 1500 MB
Overlay filesystem on external SD card
ü
Overlay filesystem on external SD card, Capacity depending on SD card
Firewall
ü
SSH/SFTP
ü
Synchronization via Ethernet (NTP)
ü
DNS
ü
IEC 61131 runtime system
Program memory 12 MB
Data memory 32 MB
Retain memory 512 KB
Realtime clock
Realtime clock
ü
Accuracy Realtime clock 1 minute deviation per month
Buffered time 28 days @ 25°C
Execution and Synchronization Manager (ESM)
Execution and Synchronization Manager (ESM)
ü
Min. task cycle time (ESM) 500 µs
ESM cores 1
Maximum parallel tasks 16
