HB700 | CPU | PMC921xEx | en | 24-04 91
Deployment CPU iC921xM-EC
Commissioning > Online access to the CPU
Assignment via WBM
2. Set the interface ‘
LAN (X3/X4)’ and click on
.
🡆 A connection between iCube Engineer and your CPU is established, by means
of the IP address parameters, and the login dialog for authentication is opened.
3. Enter your login details and click on .
On delivery
, the following access data are preset with administrator
rights:
−
Username: admin
−
The password is printed under the front flap on the front of the
CPU.
🡆 Now you can access your CPU. An existing connection is shown in the Plant
area at the node of the CPU by
.
4.5.2.1 Assigning new IP address parameters
As soon as you are online connected to the CPU, you can assign new IP address
parameters to it via WBM (W
eb-based management).
