1 Overview of the MP2300
1.4.2 Devices Connectable to MECHATROLINK-III
1-8
1.4.2 Devices Connectable to MECHATROLINK-III
The devices that are compatible with MECHATROLINK-III and can be connected to the SVC-01 Module are listed
below.
( 1 ) Compatible SERVOPACKs
( 2 )
Compatible
Inverters
( 3 ) Compatible Modules
Model Number Details
SGDV-2
SGDV SERVOPACKs with MECHATROLINK-III Communications References
SGD7S-20
SGD7S SERVOPACKs with MECHATROLINK-III Communications Refer-
ences
SGD7W-20
SGD7W SERVOPACKs with MECHATROLINK-III Communications Refer-
ences
Model Number Details
CIMR-A
SI-ET3
High Performance Vector Control Drive A1000
MECHATROLINK-III Option Card
CIMR-V
SI-ET3/V
Compact Vector Control Drive V1000
MECHATROLINK-III Option Unit
Model Number Details
JAPMC-MC2320-E
SVC-01 Motion Module
JEPMC-MTD2310-E
64-point I/O Module
24 VDC, 64 inputs, 64 outputs
JEPMC-MTA2900-E
Analog Input Module
Analog input, 8 channels
JEPMC-MTA2910-E
Analog Output Module
Analog output, 4 channels
JEPMC-MTP2900-E
Pulse Input Module
Pulse input, 2 channels
JEPMC-MTP2910-E
Pulse Output Module
Pulse output, 4 channels
