B
Current Values and Set Values (Input Data) in the SVB Definition Window
A-12
( 7 ) Saving Data to Flash Memory
The data flow for SERVOPACK parameters is as follows when saving the parameters to flash memory on the MPE720:
• The MP2300 writes the parameters data (Input Data) held in SDRAM to flash memory.
Save to flash memory also after having changed set data of SERVOPACK parameter.
B.2 Precautions When Saving SERVOPACK Parameters
Before executing saving operation in the SERVOPACK Tab Page in any cases including the SERVOPACK replace-
ment, always select Edit - Copy Current Value to copy the values in Current Value to Input Data.
MECHATROLINK
RAM
EEP
-ROM
SRAM
SDRAM
Input
Data
MPE720 㧔online㧕
HDD in personal computer
Display
Current
Value
Input
Data
Flash
Memory
System
Software
Control
Software
Servo Parameters
(All Axes)
Parameters
SERVOPACK SERVOPACK
Send Send
MP2300
