2.1 MP2300 Basic Module Specifications
This section describes the Basic Module Specifications of the MP2300.
2.1.1 Hardware Specifications
The following table shows the hardware specifications of the Basic Module.
* For the external 24 V power supply, select a power supply which satisfies the specifications below as well as the
rated current (not more than 1 A):
Allowable output load capacity: 1200 μF or more
Overcurrent detection is automatically restored by removing causes
However, except that the primary side (AC side) of the external 24 V power supply is turned ON/OFF.
Note: Recommended external 24 V power supply: RTW24-2R2 (manufactured by TDK)
Item Specifications
Classification
Basic Module
Name
MP2300
Model Number
JEPMC-MP2300 (-E)
Power
Unit
Input Voltage
24 VDC (
± 20%)
Input Current*
1 A max. (during input/output rating)
Inrush Current*
40 A max. (full discharge state, during output rating, or the secondary output of the
external 24 V power supply is turned ON)
Allowable Power Loss
Time
2 ms
Rated Voltage
5.0 V
Rated Current
4.0 A
Output Current Range
0.0 to 4.0 A
Constant Voltage
Precision
±5% max. (including input voltage and output load fluctuations)
Battery
Battery for memory retention attachable
Flash Memory
8 MBytes (User area 5.5 MBytes)
SDRAM
16 MBytes
SRAM
256 kByte: M registers, S registers, trace memory, alarm history (battery backup)
Motion Network
MECHATROLINK: 1 channel
SERVOPACK and I/O for up to 21 stations connectable (SERVOPACK for up to 16
axes)
Baud rate: 4 Mbps (MECHATROLINK-I) or 10 Mbps (MECHATROLINK-II)
Calendar
Seconds to year timer
(Battery backup)
Connectors
POWER: Power supply connector
M-I/II: MECHATROLINK connector
CPU I/O: I/O connector
Indicators
RDY(green), RUN(green), ALM(red), ERR(red), TX(green), BAT(red)
Switches
STOP, SUP, INIT, CNFG, MON, TEST
Current Consumption
1 A max.
Dimensions (mm)
120 × 130 × 108 (W × H × D)
Mass
450 g
