Setting Parameter List
A-21
Appendices
App
OW

01
Mode Setting 1
Bit 0: Excessive Deviation Error Level Setting
(0: Alarm/1: Warning)
Yes
Bits 1 to 2: Reserved for system use.
Bit 3: Speed Loop P/PI Switch
Yes
Bit 4: Gain Switch
Yes
Bit 5: Gain Switch 2
Yes
Bit 6: Latch mode selection (0: Usual latch/1: Continuous latch)
Yes
Bits 7 to F: Reserved for system use.
OW

02
Mode Setting 2
Bit 0: Monitor 2 Enabled (0: Disabled/1: Enabled)
Yes
Bits 1 to F: Reserved for system use.
OW

03
Function Setting 1
Bits 0 to 3: Speed Unit Selection
0: Reference unit/s
1: 10
n
reference unit/min
2: Percentage of rated speed (1 = 0.01%)
3: Percentage of rated speed (1 = 0.0001%)
Yes Yes
Bits 4 to 7: Acceleration/Deceleration Degree Unit Selection
0: Reference unit/s
2
1: ms
Yes Yes
Bits 8 to B: Filter Type Selection
0: No filter
1: Exponential acceleration/deceleration filter
2: Moving average filter
Yes Yes
Bits C to F: Torque Unit Selection
0: Percentage of rated toque (1 = 0.01%)
1: Percentage of rated toque (1 = 0.0001%)
Yes Yes
OW

04
Function Setting 2
Bits 0 to 3: Latch Detection Signal Selection
0: -
1: -
2: Phase-C pulse input signal
Yes
3: /EXT1
Yes
4: /EXT2
Yes
5: /EXT3
Yes
Bits 4 to 7: External Positioning Signal Setting
0:
−
1:
−
2: Phase-C pulse input signal
Yes
3: /EXT1
Yes
4: /EXT2
Yes
5: /EXT3
Yes
Bits 8 to B: Reserved for system use.
Bits C to F: Bank Selector
Yes
OW

05
Function Setting 3
Bit 1: Phase Reference Creation Calculation Disable (0: Enabled/1:
Disabled)
Yes
Bits 2 to A: Reserved for system use.
Bit B: Zero Point Return Input Signal (0: OFF/1: ON)
Yes
Bits C to F: Reserved for system use.
OW

06 to
OW

07
−
Reserved for system use.
−−
(cont’d)
Register No. Name Contents SVB SVR
