1.5.1 Cables
1-10
AO-01 CN1
Analog external outputs
JEPMC-W6090-
• Loose wires on one end
Used between
AO-01 and Analog external input device
DO-01 CN1, CN2
External outputs
JEPMC-W6060-
• Loose wires on one end
Used between
DO-01 and External I/O device
CNTR-01 CN1
External I/O
JEPMC-W2063-
• Loose wires on one end
Used between
CNTR-01 and Encoder
PO-01 CN1, CN2
PO-01 cable for module
JEPMC-W6060-
• Loose wires on one end
Used between PO-01 and External I/O
device
218IF-01
10Base-T
Ethernet communication
cable
Use a commercially avail-
able cable.
Cross cable (Category 3 min.)
PORT
RS-232C communication
cable
JEPMC-W5310-
Used between RS-232C port and 25-pin
male D-sub connector
JEPMC-W5311- Used between RS-232C port and DOS/V
218IF-02
Ethernet
Ethernet communication
cable
Use a commercially avail-
able cable.
Cross or Straight cable (Category 5)
PORT
RS-232C communication
cable
JEPMC-W5310-
Used between RS-232C port and 25-pin
male D-sub connector
JEPMC-W5311- Used between RS-232C port and DOS/V
217IF-01
RS422/485
RS-422/RS-485 communica-
tion cable
Use a commercially avail-
able cable.
• Module-side connector:
1010214-52A2JL (manufactured by
3M Japan Limited)
• Cable-side connector:
10114-3000PE (manufactured by 3M
Japan Limited)
• Shell: 10314-52A0-008 (manufactured
by 3M Japan Limited)
PORT
RS-232C communication
cable
JEPMC-W5310-
Used between RS-232C port and 25-pin
male D-sub connector
JEPMC-W5311- Used between RS-232C port and DOS/V
260IF-01
DeviceNet
DeviceNet communication
cable
Use a commercially avail-
able cable.
Module-side connector:
MSTB2.5/5-GF-5.08AU
(manufactured by Phoenix Contact K.K.)
PORT
RS-232C communication
cable
JEPMC-W5310-
Used between RS-232C port and 25-pin
male D-sub connector
JEPMC-W531
1- Used between RS-232C port and DOS/V
261IF-01
PROFIBUS
PROFIBUS communication
cable
Use a commercially avail-
able cable.
Module-side connector:
17LE-13090-27/(D33C)
(manufactured by DDK Ltd.)
PORT
RS-232C communication
cable
JEPMC-W5310-
Used between RS-232C port and 25-pin
male D-sub connector
JEPMC-W5311- Used between RS-232C port and DOS/V
262IF-01 FL-net
Ethernet communication
cable
Use a commercially avail-
able cable.
Cross or Straight cable (Category 5)
263IF-01 EtherNet/IP
264IF-01 EtherCAT
265IF-01 CompoNet
CompoNet communication
cable
For details, refer to the “Construction
Manual” issued by ODVA.
266IF-01
PROFINET
Ethernet communication
cable
Cross or Straight cable (Category 5)
266IF-02
267IF-01 CC-Link
CC-Link communication
cable
CC-Link dedicated cables (three-core
shielded twisted-pair cables)
269IF-01
CC-Link
IE Field
Ethernet communication
cable
Cross or Straight cable (Category 5)
(cont’d)
Module
Connector
Name
Application Model Specifications
