Indication of Reverse Signals
In this manual, the names of reverse signals (ones that are valid when low) are written with a forward slash (/) before
the signal name, as shown in the following example:
Notation Examples
■
Related Manuals
The following table lists the manuals relating to the MP2300. Refer to these manuals as required.
• S-ON
= /S-ON
• P-CON
= /P-CON
Manual Name Manual Number Contents
Machine Controller MP2000 Series Built-in SVB/
SVB-01 Motion Module User’s Manual
SIEP C880700 33
Describes the functions, specifications, and
application methods of the MP2000 Series Motion
Module that is built into the SVB, SVB-01, and SVR
Module.
Machine Controller MP2000 Series
SCV-01 Motion Module User’s Manual
SIEP C880700 41
Describes the functions, specifications, and
application methods of the SVC-01, SVC Motion
Module for the MP2000 Series.
Machine Controller MP2000 Series
Built-in SVA-01 Motion Module User’s Manual
SIEP C880700 32
Describes the functions, specifications, and
application methods of the SVA-01, SVA Motion
Module for the MP2000 Series.
Machine Controller MP2000 Series
Pulse Output Motion Module PO-01
User’s Manual
SIEP C880700 28
Describes the functions, specifications, and
application methods of the PO-01, Pulse Output
Motion Module for the MP2000 Series.
Machine Controller MP2000 Series
MPU-01 Multiple-CPU Module User’s Manual
SIEP C880781 05
Describes the functions, specifications, and
application methods of the Multiple-CPU Module for
the MP2000 Series.
Machine Controller MP2000 Series
Communication Module
User’s Manual
SIEP C880700 04
Describes the functions, specifications, and
application methods of the MP2000 Series
Communication Modules (218IF-01, 218IF-02,
217IF-01, 260IF-01, 261IF-01, 215IF-01).
Machine Controller MP2000 Series
I/O Module User’s Manual
SIEP C880700 34
Describes the functions, specifications, and
application methods of the I/O Module for the
MP2000 Series.
Machine Controller MP2000 Series Analog
Input/Analog Output Module AI-01/AO-01
User’s Manual
SIEP C880700 26
Describes the functions, specifications, and
application methods of the Analog Input Module
AI-01 and Analog Output Module AO-01 for the
MP2000 Series.
Machine Controller MP2000 Series
Counter Module CNTR-01 User’s Manual
SIEP C880700 27
Describes the functions, specifications, and
application methods of the Counter Module
CNTR-01 for the MP2000 Series.
Machine Controller MP2000 Series
262IF-01 FL-net Communication Module
User’s Manual
SIEP C880700 36
Describes the functions, specifications, and
application methods of the 262IF-01, FL-net
Communication Module for the MP2000-series
Machine Controllers.
Machine Controller MP2000 Series
263IF-01 EtherNet/IP Communication Module
User’s Manual
SIEP C880700 39
Describes the functions, specifications, and
application methods of the 263IF-01, EtherNet/IP
Communication Module for the MP2000 Series.
Machine Controller MP2000 Series
EtherCAT Module 264IF-01User’s Manual
SIEP C880700 42
Describes the functions, specifications, and
application methods of the 264IF-01, EtherCAT
Module for the MP2000 Series.
Machine Controller MP2000 Series
265IF-01 CompoNet Module User’s Manual
SIEP C880700 44
Describes the functions, specifications, and
application methods of the 265IF-01, CompoNet
Module for the MP2000 Series.
Machine Controller MP2000 Series
266IF-01 PROFINET Controller Module
User’s Manual
SIEP C880700 47
Describes the functions, specifications, and
application methods of the 266IF-01, PROFINET
Controller Module for the MP2000-series Machine
Controllers.
