4.3
Starting Sample Program - MPE720 Ver 5.
4-25
4
System Startup and Sample Programs
( 2 ) Creating Group Folders (Option)
In the File Manager Window, create a group folder for storing order folders.
Refer to Group Folders, Order Folders, Controller folders at the bottom of this page for more information about
these folders.
1.
Right-click (root) and select New - Group Folder from the pop-up menu.
The Make New Folder Dialog Box will appear.
2.
Enter a group folder name of up to 8 characters and click the OK Button.
A new group folder will be created. Double-click (root) or click to display the entered group folder name.
Group folders, order folders, and PLC folders form part
of a directory tree, as shown in the figure to the left.
Programs created using MPE720 are saved to PLC
folders.
MPE720 cannot create programs if no PLC folder
exists. PLC folders cannot be created if no order folder
exists. For this reason, always create an order folder and
PLC folder. Creating group folders is optional.
Group
folders
Order
folders
Controller
folders
■
Group, Order, and PLC folders
To Next Page
