A.2 Parameter Table
YASKAWA ELECTRIC SIEP C710606 10A YASKAWA AC Drive - V1000 PRELIM. Programming Manual 331
Parameter List
A
61 External Search Command 1
Closed: Activates Current Detection Speed Search from
the max. output frequency (E1-04) if b3-01=0. Activates
Speed Estimation Type Speed search if b3-01 =1.
OOO153
62 External Search Command 2
Closed: Activates Current Detection Speed Search from
the frequency reference b3-01=0. Activates Speed
Estimation Type Speed search if b3-01 =1.
OOO153
65 KEB Ride-Thru 1 (N.C.)
Open: KEB Ride-Thru 1 enabled
Closed: Normal operation
OOO153
66 KEB Ride-Thru 1 (N.O.)
Open: Normal operation
Closed: KEB Ride-Thru 1 enabled
OOO153
67 Communications Test Mode Tests the MEMOBUS/Modbus RS-485/422 interface. O O O 153
68 High-Slip Braking Closed: High-Slip braking is executed. Drive stops. O - - 153
6A Drive Enable
Open: Drive disabled.
If this input is opened during run, then the drive will stop
as specified by parameter b1-03.
Closed: Ready for operation.
OOO154
75 Up 2 Command Open: Maintains the current frequency reference
Closed: Increases or decreases the frequency reference.
UP 2 and Down 2 commands must be set in combination
with each other. The frequency reference source must be
assigned to the operator (b1-01 = “0”).
OOO154
76 Down 2 Command O O O 154
7A KEB Ride-Thru 2 (N.C.)
Open: KEB Ride-Thru 2 enabled
Closed: Normal operation
OOO156
7B KEB Ride-Thru 2 (N.O.)
Open: Normal operation
Closed: KEB Ride-Thru 2 enabled
OOO156
7C Short-Circuit Braking (N.O.)
Open: Normal operation
Closed: Short-Circuit Braking
--O156
7D Short-Circuit Braking (N.C.)
Open: Short-Circuit Braking
Closed: Normal operation
--O156
7E Forward/Reverse Detection
Direction of rotation detection (for V/f with Simple PG
Feedback)
O- -156
7F
Bi-directional PID output
selection
Enables or disables conversion of PID output to bi-
directional reference if parameter d4-11 = 1.
Open: Bi-directional output disabled
Closed: Bi-directional output enabled
OOO
HID
DE
N
90 to 96 FBD’s Digital Inputs 1 to 7 Reserved for FBD’s input functions O O O 157
9F FBD’s enable
Open: FBD’s enabled
Closed: FBD’s disabled
OOO157
H1 Multi-Function Digital Input Selections
H1-
Setting
Function Description
Control
Mode
Pg.
V/f
OL
V
PM
