4
169
USING THE DIGITAL OPERATOR
This chapter describes the basic operation of the digital operator and the con-
venient features it offers.
All constant settings and motor operations are possible by simple, conve-
nient, operation.
Operate the digital operator as you read through this chapter.
4.1 Basic Operations 170.........................
4.1.1 Connecting the Digital Operator 170.......................
4.1.2 Resetting Servo Alarms 171.............................
4.1.3 Basic Functions and Mode Selection 172...................
4.1.4 Operation in Status Display Mode 173.....................
4.1.5 Operation in User Constant Setting Mode 176...............
4.1.6 Operation in Monitor Mode 179..........................
4.2 Using the Functions 183.......................
4.2.1 Operation in Alarm Trace-back Mode 183..................
4.2.2 Operation Using the Digital Operator 186...................
4.2.3 Autotuning 188.......................................
4.2.4 Reference Offset Automatic Adjustment 195................
4.2.5 Speed Reference Offset Manual Adjustment Mode 197........
4.2.6 Clearing Alarm Trace-back Data 200......................
4.2.7 Checking Motor Type 201...............................
4.2.8 Checking Software Version 201..........................
4
