5.2 SGM Servomotor
217
5.2 SGM Servomotor
This section presents tables of ratings and specifications for SGM and SGMP
Servomotors. Refer to these tables when selecting a Servomotor.
5.2.1 Ratings and Specifications 217........................................
5.2.2 Mechanical Characteristics 230........................................
5.2.1 Ratings and Specifications
1) The ratings and specifications of SGM and SGMP Servomotors are shown below. Refer
to them as required when selecting a Servomotor.
2) Ratings and Specifications of 200-VAC SGM Servomotors
Time rating: continuous
Heat resistance class: Class B (Class A for UL spec. type SGM-jU)
Vibration class: 15µm or below
Withstand voltage: 1500 VA C
Insulation resistance: 500 VDC 10MΩ min.
Enclosure: totally enclosed, self-cooled
Ambient temperature: 0 to 40°C
Ambient humidity: 20% to 80% (non-condensing)
Excitation: permanent magnet
Drive method: direct drive
Mounting: flange method
5
To Next Page
