5.4 Σ-Series Dimensional Drawings
329
5.4.3 Servopack Dimensional Drawings
1) The dimension drawings of the DR2 Servopack are broadly grouped into the following
two categories according to capacity and option specifications (semi-closed or full-
closed loop).
a) Semi-closed loop (standard)
200V, 30W (0.04 HP) to 200 W (0.27HP) (Types: DR2-A3A
j
to 02A
j)
100V, 30W (0.04 HP) to 100 W (0.13HP) (Types: DR2-A3B
j
to 01B
j)
b) Semi-closed loop (standard)
200V
, 400W (0.53 HP), 750W (1.01 HP) (Types: DR2-04Aj, 08Aj)
100V, 200W (0.27 HP), 300W (0.40 HP) (Types: DR2-02Bj,03Bj)
c) Full-closed loop (option)
200V, 30W (0.04 HP) to 200W (0.27 HP) (Types: DR2-A3Aj-F to 02Aj-F)
100V, 30W (0.04 HP) to 100W (0.13 HP) (Types: DR2-A3Bj-F to 01Bj-F)
d) Full-closed loop (option)
200V, 400W (0.53 HP) to 750W (1.01 HP) (Types: DR2-04Aj-F to 08Aj-F)
100V, 200W (0.27 HP) to 300W (0.40 HP) (Types: DR2-02Bj-F to 03Bj-F)
5
