5.4.4 Digital Operator Dimensional Drawing
334
5.4.4 Digital Operator Dimensional Drawing
a) JUSP-OP02A-1 (Hand-held type)
TYPE:17JE-23090-02
Made by
DAIICHI
DENSHI KOGYO K.K.
Approx. Mass: 0.18 kg (0.40 lb)
(2-φ0.18)
MTG HOLES
(4.92)
(2.48)
(1.97)
(5.31)
(0.31)
(39.37)
(0.73)
(0.28)
Note Mount type digital operator (type: JUSP-OP03A) cannot be used for DR2 Servopack.
