SERVO SELECTION AND DATA SHEETS
5.4.2 Servomotor Dimensional Drawings cont.
298
• Details of Motor and Encoder Plugs (Common for 30 W (0.04 HP) to 750 W (1.01 HP)
Socket: 170362 -1 or 170366-1
Motor Plug
Pin: 170360-1 or 170364-1
(17359-1 or 170363-1: 30, 50, or
100 W only)
Cap: 172160-1
Encoder Plug
Incremental Encoder Wiring Specifications
Blue
Blue/Black
Yellow
Yellow/Black
Green
Green/Black
Gray
Red
Orange
Plug: 172169-1 (AMP)
Pin: 170359-1 or 170363-1
Plug : 172168-1 (AMP)
Connected to
Connected to
Cap :172161-1
Socket: 170361-1 or 170365-1
Motor Wiring Specifications
U phase
Red
V phase
White
W phase
Blue
FG
Green/Yellow
1
2
3
4
Brake terminal
Red5
Brake terminal Black
6
A channel output
A
channel output
B channel output
B
channel output
FG (Frame Ground)
C
channel output
C channel output
0 V (power supply)
+5 V (power supply)
1
2
3
4
5
6
7
8
9
5
