YASKAWA SGM-A3

491
2) Applicable Servomotor and Servopack
•
Servomotor : (with incremental encoder)
•
Servopack : DR2-
j
-F
••••
Full-closed feedback input conditions:
1
Line driver output from linear scale
2
Max. frequency : 675kPPS
4500
×
1.1
60
×
8192
( ≒
675kPPS)
3
Linear scale evaluation magnification : 4
3) Applicable Linear Scale
• Manufacturer :
• Type : , Scale Interval : mm
• Waveform Shaping Circuit : Type =
(Detector EXE, interpolation digital circuit unit)
Max. operation speed = m/min
Max. input frequency = kHz
Output signal form =
Interpolation magnification = •••• (Conditions under the
Evaluation magnification = combination with
Measuring pitch = µm linear scale)
Min. edge interval = µs ••••(Combination with Max.
Min. pulse width = µs input frequency)
G
