4.6.4 Operator Display during Testing without Motor
The status display changes as shown below to show that the test without motor is in progress.
(1) Display on Panel Operator
∗ The test without motor operation is indicated with tSt.
Note: The test without motor status is not displayed during alarm occurs (A.).
(2) Display on Digital Operator
∗ mark is displayed before status display to indicate the test without motor operation is in progress.
(Example: Status of power to the motor is OFF)
Note: The test without motor status is not displayed during alarm occurs (A.).
Display Status
run ⇔ tSt
Power is supplied to the motor.
bb ⇔ tSt
Power to the motor is OFF.
Pot ⇒ not ⇒ tSt
Forward or reverse rotation is prohibited.
Pot ⇔ tSt
Driving in the forward direction is prohibited.
not ⇔ tSt
Driving in the reverse direction is prohibited.
Hbb ⇔ tSt
In hard-wire base block (safety) state.
Display Status
*RUN Power is supplied to the motor.
*BB Power to the motor is OFF.
*P DET The polarity is being detected.
*PT NT Forward or reverse rotation is prohibited.
*P-OT Driving in the forward direction is prohibited.
*N-OT Driving in the reverse direction is prohibited.
*HBB In hard-wire base block (safety) state.
