3.2.2 I/O Signal Connector (CN1) Terminal Layout
3-18
3.2.2 I/O Signal Connector (CN1) Terminal Layout
The following table shows the terminal layout of I/O signal connectors (CN1).
Note 1. Do not use unused terminals.
2. Connect the shield of the I/O signal cable to the connector shell.
Connect to the FG (frame ground) at the SERVOPACK connector.
3. The functions allocated to the following input and output signals can be changed to /CLT, /VLT, /BK, /WARN or
/NEAR signals by using the parameters. Refer to 3.3.1 Input Signal Allocations and 3.3.2 Output Signal Alloca-
tions.
Input signals: /S-ON, /P-CON, P-OT, N-OT, /ALM-RST, /P-CL, and /N-CL
Output signals: /TGON, /S-RDY, and /V-CMP (/COIN)
1SG GND 26
/V-CMP-
(/COIN-)
Speed
coincidence
detection
output
2 SG GND 27 /TGON+
TGON signal
output
3PL1
Power supply
for open-
collector
reference
28 /TGON-
TGON signal
output
4 SEN
SEN signal
input
29 /S-RDY+
Servo ready
output
5V-REF
Speed
reference
input
30 /S-RDY-
Servo ready
output
6SG GND 31ALM+
Servo alarm
output
7PULS
Reference
pulse input
32 ALM-
Servo alarm
output
8/PULS
Reference
pulse input
33 PAO
Encoder
output pulse
Phase A
9T-REF
Torque
reference
input
34 /PAO
Encoder
output pulse
Phase A
10 SG GND 35 PBO
Encoder
output pulse
Phase B
11 SIGN
Reference
sign input
36 /PBO
Encoder
output pulse
Phase B
12 /SIGN
Reference
sign input
37 ALO1
Alarm code
output
13 PL2
Power supply
for open-
collector
reference
38 ALO2
Alarm code
output
14 /CLR Clear input 39 ALO3
Alarm code
output
15 CLR Clear input 40 /S-ON
Servo ON
inp
ut
16 −− 41 /P-CON P control input
17 −− 42 P-OT
Forward run
prohibit input
18 PL3
Power supply
for open-
collector
reference
43 N-OT
Reverse run
prohibit input
19 PCO
Encoder
output pulse
Phase C
44
/ALM-
RST
Alarm reset
input
20 /PCO
Encoder
output pulse
Phase C
45 /P-CL
Forward
external torque
limit input
21 BAT (+) Battery (+) 46 /N-CL
Reverse
external
torque limit
input
22 BAT (-) Battery (-) 47
+24 V
IN
External input
power supply
23 −− 48 −−
24 −− 49 −−
25
/V-CMP+
(/COIN+)
Speed
coincidence
detection
output
50 −−
