1.3 SERVOPACK Ratings and Specifications
This section describes the ratings and specifications of SERVOPACKs.
1.3.1 Ratings
Ratings of SERVOPACKs are as shown below.
(1)
100 VAC Rating
(2)
200 VAC Rating
(3)
400 VAC Rating
SGDV (100 VAC) R70 R90 2R1 2R8
Continuous Output Current
[Arms]
0.66 0.91 2.1 2.8
Max. Output Current [Arms] 2.1 2.9 6.5 9.3
Main Circuit Power Supply
Single-phase, 100 to 115 VAC , 50/60 Hz
Control Power
Single-phase, 100 to 115 VAC , 50/60 Hz
Overvoltage Category III
SGDV (200 VAC) R70 R90 1R6 2R8 3R8 5R5 7R6 120 180 200 330 470 550 590 780
Continuous Output Current
[Arms]
0.66 0.91 1.6 2.8 3.8 5.5 7.6 11.6 18.5 19.6 32.9 46.9 54.7 58.6 78.0
Max. Output Current [Arms] 2.1 2.9 5.8 9.3 11.0 16.9 17 28 42 56 84 110 130 140 170
Main Circuit Power Supply
Three-phase, 200 to 230 VAC , 50/60 Hz
Control Power
Single-phase, 200 to 230 VAC , 50/60 Hz
Overvoltage Category III
SGDV (400 VAC) 1R9 3R5 5R4 8R4 120 170 210 260 280 370
Continuos Output Current
[Arms]
1.9 3.5 5.4 8.4 11.9 16.5 20.8 25.7 28.1 37.2
Max. Output Current [Arms] 5.5 8.5 14 20 28 42 55 65 70 85
Main Circuit Power Supply
Three-phase, 380 to 480 VAC , 50/60 Hz
Control Power 24 VDC ±15%
Overvoltage Category III
