5 Operation
5.2.5 Stopping Servomotors after /S_ON Turned OFF or Alarm Occurrence
5-14
(2) Stopping Method for Servomotor When an Alarm Occurs
There are two type of alarms (Gr.1 and Gr.2), depending on the stopping method when an alarm occurs.
Select the stopping method for the servomotor when an alarm occurs using Pn001.0 and Pn00B.1.
The stopping method for the servomotor for a Gr.1 alarm (alarms that result in a DB stop) is set to Pn001.0.
The stopping method for the servomotor for a Gr.2 alarm (alarms that result in a zero-speed stop) is set to
Pn00B.1.
Refer to the information on alarm stopping methods in 10.1.1 List of Alarms.
 Stopping Method for Servomotor for Gr.1 Alarms
The stopping method of the servomotor when a Gr.1 alarm occurs is the same as that for the servomotor after
the /S_ON (Servo ON) signal turns OFF.
 Stopping Method for Servomotor for Gr.2 Alarms
Note: The setting of Pn00B.1 is effective for position control and speed control. Pn00B.1 will be ignored for torque control
and only the setting of Pn001.0 will be valid.
Parameter Stop Mode
Mode After
Stopping
Meaning When Enabled Classification
Pn001
n.0
Stop by
dynamic
brake
Dynamic
Brake
Stops the servomotor by
dynamic braking (DB), then
holds it in Dynamic Brake
Mode. [Factory setting]
After restart Setup
n.1 Coast
Stops the servomotor by
dynamic braking (DB), then
places it into Coast Mode.
n.2
Coast to a
stop
Coast
Stops the servomotor by coast-
ing and continues in Coast
Mode.
Parameter
Stop Mode
Mode After
Stopping
Meaning
When
Enabled
Classifica-
tion
Pn00B Pn001
n.0
[Factory
setting]
n.0
[Factory setting]
Zero-speed
stopping
Dynamic
Brake
Stops the servomotor by zero-speed stop,
then holds it in Dynamic Brake Mode.
After
restart
Setup
n.1
Coast
Stops the servomotor by zero-speed stop,
then places it into Coast Mode.
n.2
Stops the servomotor by zero-speed stop,
then places it into Coast Mode.
n.1
n.0
[Factory setting]
Stops by
dynamic
brake
Dynamic
Brake
Stops the servomotor by dynamic braking
(DB), then holds it in Dynamic Brake
Mode.
n.1
Coast
Stops the servomotor by dynamic braking
(DB), then places it into Coast Mode.
n.2 Coast to stop
Stops the servomotor by coasting and
continues in Coast Mode.
