(2) Failure in Operation
If "NO-OP" is shown
If "Error" is shown
8
Press the Key. The adjusted values will be writ-
ten to the SERVOPACK, "DONE" will blink for two
seconds, and "ADJ" will be displayed.
Note: Not to save the values set in step 6, press the
Key.
9
Press the Key to complete the advanced autotun-
ing by reference operation. The screen in step 1 will
appear again.
10 To enable the change in the setting, turn OFF the power and ON again.
Probable Cause Corrective Actions
The main circuit power supply was OFF. Turn ON the main circuit power supply.
An alarm or warning occurred. Remove the cause of the alarm or the warning.
Overtraveling occurred. Remove the cause of the overtravel.
Gain setting 2 was selected by gain switching. Turn OFF the automatic gain switching.
Error Probable Cause Corrective Actions
The gain adjustment
was not successfully
completed.
Machine vibration is occurring or the posi-
tioning completed signal (/COIN) is turning
ON and OFF.
• Increase the set value for Pn522.
• Change the mode from 2 to 3.
• If machine vibration occurs, suppress the
vibration with the anti-resonance control
adjustment function and the vibration sup-
pression function.
The positioning
completed signal
(/COIN) did not turn ON
within approximately 10
seconds after
positioning adjustment
was completed.
The positioning completed width is too nar-
row or the proportional control (P control) is
being used.
Increase the set value for Pn522. If P control
is used, turn OFF the /P-CON signal.
Step Display after Operation Keys Operation
