YASKAWA V1000 User Manual

Item Specification
Three-Phase: CIMR-Vo2A
0001 0002 0004 0006 0010 0012 0020
Single-Phase: CIMR-VoBA
<1>
0001 0002 0003 0006 0010 0012
0018
<2>
Harmonic Corrective
Actions
DC Link Choke Optional
<1> Drives with single-phase power supply input will output three-phase power and cannot run a single-phase motor.
<2>
CIMR-VoBA0020 only. CIMR-VoBA0018 is available with a Heavy Duty rating only.
<3> The motor capacity (HP) refers to a NEC rated 4-pole motor. The rated output current of the drive output amps
should be equal to or greater than the motor rated current.
<4> Input current rating varies depending on the power supply transformer, input reactor, wiring connections, and
power supply impedance.
<5> Rated motor capacity is calculated with a rated output voltage of 230 V.
<6> Carrier frequency is set to 2 kHz (Swing PWM). Current derating is required in order to raise the carrier
frequency.
<7> Carrier frequency is set to 10 kHz. Current derating is required in order to raise the carrier frequency.
<8> Carrier frequency is set to 8 kHz. Current derating is required in order to raise the carrier frequency.
A.2 Single/Three-Phase 200 V Class Drives
158
YASKAWA ELECTRIC TOEP C710606 47A YASKAWA AC Drive – V1000 Quick Start Guide

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
