YASKAWA V1000 User Manual

Table A.3 Power Ratings Continued
Item Specification
Three-Phase: CIMR-Vo2A
0030 0040 0056 0069
Single-Phase: CIMR-VoBA
<1>
- - - -
Maximum Motor Size Allowed (HP)
<2>
ND Rating 7.5/10.0 10.0 20.0 25.0
HD Rating 7.5 10.0 15.0 20.0
Input
Input Current
(A)
<3>
Three-
Phase
ND Rating 37.0 52.0 68.0 80.0
HD Rating 24.0 37.0 52.0 68.0
Single-
Phase
ND Rating - - - -
HD Rating - - - -
Output
Rated Output Capacity
(kVA)
<4>
ND Rating 11.4 15.2 21.3 26.3
HD Rating 9.5 12.6 17.9 22.9
Output Current (A)
ND Rating
<5>
30.0 40.0 56.0 69.0
HD Rating
25.0
<6>
33.0
<6>
47. 0
<6>
60.0
<6>
Overload Tolerance
ND Rating: 120% of rated output current for 1 minute
HD Rating: 150% of rated output current for 1 minute
(Derating may be required for applications that start and
stop frequently)
Carrier Frequency User-adjustable 2 to 15 kHz
Max Output Voltage (V)
Three-phase power: Three-phase 200 to 240 V
Single-phase power: Three-phase 200 to 240 V
(both proportional to input voltage)
Max Output Frequency (Hz) 400 Hz (user-adjustable)
Power
Supply
Rated Voltage
Rated Frequency
Three-phase power: Three-phase 200 to 240 V 50/60 Hz
Single-phase power: 200 to 240 V 50/60 Hz
Allowable Voltage Fluctuation -15 to 10%
Allowable Frequency Fluctuation ±5%
Harmonic Corrective
Actions
DC Link Choke Optional
<1> Drives with single-phase power supply input will output three-phase power and cannot run a single-phase motor.
<2> The motor capacity (HP) refers to a NEC rated 4-pole motor. The rated output current of the drive output amps
should be equal to or greater than the motor rated current.
<3> Input current rating varies depending on the power supply transformer, input reactor, wiring connections, and
power supply impedance.
<4> Rated motor capacity is calculated with a rated output voltage of 220 V.
<5> Carrier frequency is set to 2 kHz (Swing PWM). Current derating is required in order to raise the carrier
frequency.
<6> Carrier frequency is set to 8 kHz. Current derating is required in order to raise the carrier frequency.
A.2 Single/Three-Phase 200 V Class Drives
YASKAWA ELECTRIC TOEP C710606 47A YASKAWA AC Drive – V1000 Quick Start Guide
159
A
Specifications

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
