YASKAWA V1000 User Manual

Item
Specification
Environment
Storage/Installation Area
Indoors
Ambient Temperature
IP20/NEMA Type 1 enclosure: -10 °C to +40 °C
IP20/IP00 Open-Chassis enclosure: -10 °C to +50 °C
Finless Type: IP20/IP00 enclosure: -10 °C to +50 °C
NEMA Type 4X/IP66 enclosure: -10 °C to +40 °C
Humidity
95% RH or less with no condensation
Storage Temperature
-20 to +60 °C allowed for short-term transport of the product
Altitude
Up to 1000 meters without derating; up to 3000 meters with output
current and voltage derating.
Shock, Impact
10 to 20 Hz: 9.8 m/s
2
20 to 55 Hz: 5.9 m/s
2
Surrounding Area
Install the drive in an area free from:
• oil mist and dust
• metal shavings, oil, water or other foreign materials
• radioactive materials
• combustible materials
• harmful gases and liquids
• excessive vibration
• chlorides
• direct sunlight
Orientation
Install the drive vertically to maintain maximum cooling effects
Standards
• UL508C
• EN61800-3, EN61800-5-1
• ISO13849-1 Cat.3 PLd, IEC61508 SIL2
Time from input open to drive output stop is less than 1 ms.
Protective Enclosure
IP20/Open-Chassis or IP00/Open-Chassis
<8>
IP20/NEMA Type 1
<9>
Cooling Method
CIMR-VoBA0001 to 0006: self-cooled
CIMR-VoBA0010 to 0018: cooling fan
CIMR-Vo2A0001 to 0004: self-cooled
CIMR-Vo2A0006 to 0069: cooling fan
CIMR-Vo4A0001 to 0004: self-cooled
CIMR-Vo4A0005 to 0038: cooling fan
<1> Speed control accuracy varies somewhat according to the type of motor and drive settings.
<2> Instantaneous average deceleration torque refers to the torque required to decelerate the motor (uncoupled from
the load) from the rated motor speed down to zero in the shortest time.
<3> Ensure that Stall Prevention Selection during Deceleration is disabled (L3-04 = 0) or set to 3 when using a
braking resistor or the Braking Resistor Unit. The default setting for the stall prevention function will interfere
with the braking resistor.
<4> Overload protection may be triggered when operating with 150% of the rated output current if the output
frequency is less than 6 Hz.
<5> Parameter settings allow up to 150 V.
A.4 Drive Specifications
164
YASKAWA ELECTRIC TOEP C710606 47A YASKAWA AC Drive – V1000 Quick Start Guide

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
