YASKAWA V1000 User Manual

<6> A Momentary Power Loss Ride-Thru Unit is required for 200/400 V class drives 7.5 kW and less if the application
needs to continue running during a momentary power loss up to 2 seconds.
<7> Ground protection cannot be provided under the following circumstances when a ground fault is likely in the
motor windings during run: Low ground resistance for the motor cable and terminal block; low ground resistance
for the motor cable and terminal block; or the drive is powered up from a ground short.
<8> The following models have an IP20/Open-Chassis enclosure as standard. Customers may convert these models
to IP20/NEMA Type 1 enclosures using the IP20/NEMA Type 1 Kit Option:
CIMR-Vo2A0030 to 2A0069
CIMR-Vo4A0018 to 4A0038
<9> The following models have an IP20/NEMA Type 1 enclosure as standard. For an IP20/Open-Chassis or IP00/
Open-Chassis design, remove the top and bottom covers:
CIMR-VoBA0001 to BA0018
CIMR-Vo2A0001 to 2A0020
CIMR-Vo4A0001 to 4A0011
Note: Time from input open to drive output stop is less than 1 ms.
A.4 Drive Specifications
YASKAWA ELECTRIC TOEP C710606 47A YASKAWA AC Drive – V1000 Quick Start Guide
165
A
Specifications

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
