YASKAWA V1000

No. Name Description
C3-01 Slip Compensation Gain Sets the slip compensation gain.
C3-02
Slip Compensation Primary Delay
Time
Adjusts the slip compensation function delay time.
C3-03 Slip Compensation Limit Refer to V1000 Technical Manual for details.
C3-04
Slip Compensation Selection during
Regeneration
0: Disabled
1: Enabled
C3-05
Output Voltage Limit Operation
Selection
Refer to V1000 Technical Manual for details.
C4: Torque Compensation
Use C4 parameters to configure Torque Compensation function.
C4-01 Torque Compensation Gain
V/f control: Sets the gain for the automatic torque (voltage) boost
function and helps to produce better starting torque.
Open Loop Vector: Sets the torque compensation function gain.
Normally no change is required.
C4-02
Torque Compensation Primary
Delay Time
Sets the torque compensation filter time.
C4-03
Torque Compensation at Forward
Start
Refer to V1000 Technical Manual for details.
C4-04
Torque Compensation at Reverse
Start
Refer to V1000 Technical Manual for details.
C4-05
Torque Compensation Time
Constant
Refer to V1000 Technical Manual for details.
C4-06
Torque Compensation Primary
Delay Time 2
Refer to V1000 Technical Manual for details.
C5: Speed Control (ASR)
Use C5 parameters to configure the Automatic Speed Regulator (ASR).
C5 parameters are available only when using V/f with Simple PG (H6-01 = 3).
C5-01 ASR Proportional Gain 1 Refer to V1000 Technical Manual for details.
C5-02 ASR Integral Time 1 Refer to V1000 Technical Manual for details.
C5-03 ASR Proportional Gain 2 Refer to V1000 Technical Manual for details.
C5-04 ASR Integral Time 2 Refer to V1000 Technical Manual for details.
C5-05 ASR Limit Refer to V1000 Technical Manual for details.
C6: Carrier Frequency
Use C6 parameters to configure the carrier frequency drive settings.
C6-01 Drive Duty Selection Refer to V1000 Technical Manual for details.
B.1 Parameter Table
YASKAWA ELECTRIC TOEP C710606 47A YASKAWA AC Drive – V1000 Quick Start Guide
173
B
Parameter List
