YASKAWA V1000

No. Name Description
C6-02 Carrier Frequency Selection
1: 2.0 kHz
2: 5.0 kHz
3: 8.0 kHz
4: 10.0 kHz
5: 12.5 kHz
6: 15.0 kHz
7: Swing PWM 1 (Audible sound 1)
8: Swing PWM 2 (Audible sound 2)
9: Swing PWM 3 (Audible sound 3)
A: Swing PWM 4 (Audible sound 4)
B: Leakage Current Rejection PWM
C to E: No setting possible
F: User-defined (determined by C6-03 through C6-05)
Note: Setting B is available in drive software versions PRG: 1020
and later.
C6-03 Carrier Frequency Upper Limit
Refer to V1000 Technical Manual for details.
C6-04 Carrier Frequency Lower Limit
C6-05
Carrier Frequency Proportional
Gain
Refer to V1000 Technical Manual for details.
d1: Frequency Reference
Use d1 parameters to configure the drive frequency reference.
d1-01 Frequency Reference 1
Frequency reference. Refer to Frequency Reference Source: b1-01
on page 107 for instructions to use d1-01 as the main frequency
reference.
d1-02 Frequency Reference 2
Frequency reference when digital input “Multi-Step Speed Reference
1” (H1-oo = 3) is on.
d1-03 Frequency Reference 3
Frequency reference when digital input “Multi-Step Speed Reference
2” (H1-oo = 4) is on.
d1-04 Frequency Reference 4
Frequency reference when digital inputs “Multi-Step Speed
Reference 1, 2” (H1-oo = 3 and 4) are on.
d1-05 Frequency Reference 5
Frequency reference when digital input “Multi-Step Speed Reference
3” (H1-oo = 5) is on.
d1-06 Frequency Reference 6
Frequency reference when digital inputs “Multi-Step Speed
Reference 1, 3” (H1-oo = 3 and 5) are on.
d1-07 Frequency Reference 7
Frequency reference when digital inputs “Multi-Step Speed
Reference 2, 3” (H1-oo = 4 and 5) are on.
d1-08 Frequency Reference 8
Frequency reference when multi-function input “Multi-Step speed
reference 1, 2, 3” (H1-oo = 3, 4, 5) are on.
d1-09 Frequency Reference 9
Frequency reference when multi-function input “Multi-Step Speed
Reference 4” (H1-oo = 32) is on.
d1-10 Frequency Reference 10
Frequency reference when digital input “Multi-Step Speed Reference
1, 4” (H1-oo = 3 and 32) are on.
d1-11 Frequency Reference 11
Frequency reference when digital inputs “Multi-Step Speed
Reference 2, 4” (H1-oo = 4 and 32) are on.
d1-12 Frequency Reference 12
Frequency reference when digital inputs “Multi-Step Speed
Reference 1, 2, 4” (H1-oo = 3, 4, 32) are on.
B.1 Parameter Table
