YASKAWA V1000

No. Name Description
E2-07
Motor Iron-Core Saturation
Coefficient 1
Refer to V1000 Technical Manual for details.
E2-08
Motor Iron-Core Saturation
Coefficient 2
Refer to V1000 Technical Manual for details.
E2-09 Motor Mechanical Loss Refer to V1000 Technical Manual for details.
E2-10
Motor Iron Loss for Torque
Compensation
Sets the motor iron loss in watts (W).
E2-11 Motor Rated Output Sets the motor rated power in kilowatts (kW).
E2-12
Motor Iron-Core Saturation
Coefficient 3
Refer to V1000 Technical Manual for details.
E3: Motor 2 V/f Characteristics
Use E3 parameters to set the V/f pattern for a second motor.
E3-01 Motor 2 Control Method Refer to V1000 Technical Manual for details.
E3-04 Motor 2 Max Output Frequency Refer to V1000 Technical Manual for details.
E3-05 Motor 2 Max Voltage Refer to V1000 Technical Manual for details.
E3-06 Motor 2 Base Frequency Refer to V1000 Technical Manual for details.
E3-07 Motor 2 Mid Output Freq. Refer to V1000 Technical Manual for details.
E3-08 Motor 2 Mid Output Freq. Voltage Refer to V1000 Technical Manual for details.
E3-09 Motor 2 Min. Output Freq. Refer to V1000 Technical Manual for details.
E3-10 Motor 2 Min. Output Freq. Voltage Refer to V1000 Technical Manual for details.
E3-11 Motor 2 Mid Output Frequency 2 Refer to V1000 Technical Manual for details.
E3-12
Motor 2 Mid Output Frequency
Voltage 2
Refer to V1000 Technical Manual for details.
E3-13 Motor 2 Base Voltage Refer to V1000 Technical Manual for details.
E4: Motor 2 Parameters
Use E4 parameters to control a second motor operating on the same drive.
E4-01 Motor 2 Rated Current Refer to V1000 Technical Manual for details.
E4-02 Motor 2 Rated Slip Refer to V1000 Technical Manual for details.
E4-03 Motor 2 Rated No-Load Current Refer to V1000 Technical Manual for details.
E4-04 Motor 2 Motor Poles Refer to V1000 Technical Manual for details.
E4-05 Motor 2 Line-to-Line Resistance Refer to V1000 Technical Manual for details.
E4-06 Motor 2 Leakage Inductance Refer to V1000 Technical Manual for details.
E4-07
Motor 2 Motor Iron-Core Saturation
Coefficient 1
Refer to V1000 Technical Manual for details.
E4-08
Motor 2 Motor Iron-Core Saturation
Coefficient 2
Refer to V1000 Technical Manual for details.
E4-09 Motor 2 Mechanical Loss Refer to V1000 Technical Manual for details.
E4-10 Motor 2 Iron Loss Refer to V1000 Technical Manual for details.
B.1 Parameter Table
YASKAWA ELECTRIC TOEP C710606 47A YASKAWA AC Drive – V1000 Quick Start Guide
177
B
Parameter List
