No. Name Description
E4-11 Motor 2 Rated Capacity Refer to V1000 Technical Manual for details.
E4-12
Motor 2 Iron-Core Saturation
Coefficient 3
Refer to V1000 Technical Manual for details.
E4-14 Motor 2 Slip Compensation Gain Refer to V1000 Technical Manual for details.
E4-15
Torque Compensation Gain - Motor
2
Refer to V1000 Technical Manual for details.
E5: PM Motor Parameters
E5-01
Motor Code Selection (for PM
motor)
Refer to V1000 Technical Manual for details.
E5-02
Motor Rated Capacity (for PM
motor)
Refer to V1000 Technical Manual for details.
E5-03 Motor Rated Current Refer to V1000 Technical Manual for details.
E5-04 Motor Poles Refer to V1000 Technical Manual for details.
E5-05 Motor Resistance Refer to V1000 Technical Manual for details.
E5-06 Motor d Axis Inductance Refer to V1000 Technical Manual for details.
E5-07 Motor q Axis Inductance Refer to V1000 Technical Manual for details.
E5-09 Motor Induction Voltage Constant 1 Refer to V1000 Technical Manual for details.
E5-24 Motor Induction Voltage Constant 2 Refer to V1000 Technical Manual for details.
F1: Simple PG V/f Parameters
Use F1 parameters to set up the drive for Simple PG V/f control. These parameters are enabled only when H6-01 = 03
F1-02
Operation Selection at PG Open
Circuit (PGO)
Refer to V1000 Technical Manual for details.
F1-03
Operation Selection at Overspeed
(OS)
Refer to V1000 Technical Manual for details.
F1-04 Operation Selection at Deviation Refer to V1000 Technical Manual for details.
F1-08 Overspeed Detection Level Refer to V1000 Technical Manual for details.
F1-09 Overspeed Detection Delay Time Refer to V1000 Technical Manual for details.
F1-10
Excessive Speed Deviation
Detection Level
Refer to V1000 Technical Manual for details.
F1-11
Excessive Speed Deviation
Detection Delay Time
Refer to V1000 Technical Manual for details.
F1-14 PG Open-Circuit Detection Time Refer to V1000 Technical Manual for details.
F6: Serial Communications Option Card Settings
Use F6 parameters to program the drive for serial communication.
F6-01
Communications Error Operation
Selection
Refer to V1000 Technical Manual for details.
F6-02
External Fault from Comm. Option
Detection Selection
Refer to V1000 Technical Manual for details.
F6-03
External Fault from Comm. Option
Operation Selection
Refer to V1000 Technical Manual for details.
