H1 Multi-Function Digital Input Selections
H1-oo
Setting
Function Description
44 Offset Frequency 1 Addition Closed: Adds d7-01 to the frequency reference.
45 Offset Frequency 2 Addition Closed: Adds d7-02 to the frequency reference.
46 Offset Frequency 3 Addition Closed: Adds d7-03 to the frequency reference.
47 Node Setup
Closed: Node Setup for SI-S3/V enabled.
Note: Available in drive software versions PRG: 1016 and later.
60
DC Injection Braking
Command
Closed: Triggers DC Injection Braking (b2-02)
61 External Search Command 1
Closed: Activates Current Detection Speed Search from the max. output
frequency (E1-04) if b3-01 = 0.
62 External Search Command 2
Closed: Activates Current Detection Speed Search from the frequency
reference if b3-01 = 0. Activates Speed Estimation Type Speed search if
b3-01 = 0.
65 KEB Ride-Thru 1 (N.C.)
Open: KEB Ride-Thru 1 enabled
Closed: Normal operation
66 KEB Ride-Thru 1 (N.O.)
Open: Normal operation
Closed: KEB Ride-Thru 1 enabled
67 Communications Test Mode Tests the MEMOBUS/Modbus RS-485/422 interface.
68 High-Slip Braking Closed: High-Slip braking is executed. Drive stops.
6A Drive Enable
Open: Drive disabled. If this input is opened during run, then the drive will
stop as specified by parameter b1-03.
Closed: Ready for operation.
75 Up 2 Command
Open: Maintains the current frequency reference
Closed: Increases or decreases the frequency reference.
76 Down 2 Command
7A KEB Ride-Thru 2 (N.C.)
Open: KEB Ride-Thru 2 enabled
Closed: Normal operation
7B KEB Ride-Thru 2 (N.O.)
Open: Normal operation
Closed: KEB Ride-Thru 2 enabled
7C Short-Circuit Braking (N.O.)
Open: Normal operation
Closed: Short-Circuit Braking
7D Short-Circuit Braking (N.C.)
7E Forward/Reverse Detection Direction of rotation detection (for Simple V/f w/PG)
90 to 96
DriveWorksEZ Digital Input 1
to 7
These settings are for digital input functions used in DriveWorksEZ.
Normally there is no need to change or apply these settings.
9F DriveWorksEZ enable
Open: DWEZ enabled
Closed: DWEZ disabled
B.1 Parameter Table
