YASKAWA V1000 - Page 183

H1 Multi-Function Digital Input Selections
H1-oo
Setting
Function Description
14 Fault Reset Closed: Resets faults if cause is cleared and Run command removed.
15 Fast-Stop (N.O.) Closed: Decelerates at the Fast-Stop time C1-09.
16 Motor 2 Selection
Open: Motor 1 (E1-oo, E2-oo)
Closed: Motor 2 (E3-oo, E4-oo)
17 Fast-stop (N.C.) Open: Decelerates according to C1-09 (Fast-stop Time)
18 Timer Input Function Set the timer delay using parameters b4-01 and b4-02.
19 PID Disable Closed: PID control disabled
1A Accel/Decel Time Selection 2 Switches Accel/Decel times.
1B Program Lockout
Open: Parameters can not be edited. (except U1-01 if reference source is
set for operator)
Closed: Parameters may be edited and saved.
1E Reference Sample Hold
Closed: Samples the analog frequency reference and operates the drive at
that speed.
20 to 2F External Fault
20: N.O., Always Detected, Ramp To Stop
21: N.C., Always Detected, Ramp To Stop
22: N.O., During Run, Ramp To Stop
23: N.C., During Run, Ramp To Stop
24: N.O., Always Detected, Coast To Stop
25: N.C., Always Detected, Coast To Stop
26: N.O., During Run, Coast To Stop
27: N.C., During Run, Coast To Stop
28: N.O., Always Detected, Fast-stop
29: N.C., Always Detected, Fast-stop
2A: N.O., During Run, Fast-stop
2B: N.C., During Run, Fast-stop
2C: N.O., Always Detected, Alarm Only (continue running)
2D: N.C., Always Detected, Alarm Only (continue running)
2E: N.O., During Run, Alarm Only (continue running)
2F: N.C., During Run, Alarm Only (continue running)
30 PID Integral Reset Closed: Resets the PID control integral value.
31 PID Integral Hold Closed: Maintains the current PID control integral value.
32 Multi-Step Speed Reference 4 Used to select Multi-Step Speeds set in d1-01 to d1-16
34 PID Soft Starter Closed: Disables the PID soft starter b5-17.
35 PID Input Switch Closed: Inverses the PID input signal
40
Forward Run Command
(2-wire sequence)
Open: Stop
Closed: Forward run
41
Reverse Run Command (2-wire
sequence)
Open: Stop
Closed: Reverse run
42
Run Command (2-wire
sequence 2)
Open: Stop
Closed: Run
43
FWD/REV Command (2-wire
sequence 2)
Open: Reverse
Closed: Forward
B.1 Parameter Table
YASKAWA ELECTRIC TOEP C710606 47A YASKAWA AC Drive – V1000 Quick Start Guide
183
B
Parameter List
