YASKAWA V1000

No. Name Description
U1-10 Input Terminal Status Displays the input terminal status.
U1-11 Output Terminal Status Displays the output terminal status.
U1-12 Drive Status Verifies the drive operation status.
U1-13 Terminal A1 Input Voltage
Displays the analog input A1 input level.
100% when the input is 10 V.
U1-14 Terminal A2 Input Voltage
Displays the analog input A2 input level.
100% when the input is 10 V / 20 mA.
U1-16 Output Frequency after Soft Start Displays the output frequency.
U1-18 OPE Fault Parameter
Displays the parameter number for oPEoo or Err (operator error)
where the error occurred.
U1-19 MEMOBUS/Modbus Error Code Refer to V1000 Technical Manual for details.
U1-24 Input Pulse Monitor Displays the Pulse Train input RP frequency.
U1-25 Software No. (Flash) Yaskawa Flash ID
U1-26 Software No. (ROM) Yaskawa ROM ID
U1-27 Operator Message ID
Displays the numeric code of the remote operator (for use by the
manufacturer).
U1-28 Drive Message ID Displays the numeric code of the drive (for use by the manufacturer).
U2: Fault Trace
Use U2 monitor parameters to view fault trace data.
U2-01 Current Fault Display of the current fault.
U2-02 Previous Fault Display of the previous fault.
U2-03
Frequency Reference at Previous
Fault
Displays the frequency reference at the previous fault.
U2-04
Output Frequency at Previous
Fault
Displays the output frequency at the previous fault.
U2-05 Output Current at Previous Fault Displays the output current at the previous fault.
U2-06 Motor Speed at Previous Fault Displays the motor speed at the previous fault.
U2-07 Output Voltage at Previous Fault Displays the output voltage at the previous fault.
U2-08 DC Bus Voltage at Previous Fault Displays the DC bus voltage at the previous fault.
U2-09 Output Power at Previous Fault Displays the output power at the previous fault.
U2-10
Torque Reference at Previous
Fault
Displays the torque reference at the previous fault.
U2-11
Input Terminal Status at Previous
Fault
Displays the input terminal status at the previous fault. Displayed as in
U1-10.
U2-12
Output Terminal Status at Previous
Fault
Displays the output status at the previous fault.
U2-13
Drive Operation Status at Previous
Fault
Displays the operation status of drive at the previous fault.
B.1 Parameter Table
198
