YASKAWA V1000

No. Name Description
o4-11 U2, U3 Initialize Selection
0: Saves the fault monitor data.
1: Resets the fault monitor data to 0.
o4-12 kWh Monitor Initialization Refer to V1000 Technical Manual for details.
o4-13
Number of Run commands
Initialize selection
Refer to V1000 Technical Manual for details.
q: DWEZ Parameters
q1-01 to
q6-07
DWEZ Parameters Reserved for DriveWorksEZ.
r: DWEZ Connection Parameters
r1-01 to
r1-40
DWEZ Connection Parameters 1 to
20 (upper/lower)
Please refer to the Help file included with the DriveWorksEZ software
package for details.
T: Motor Tuning
Enter data into the following parameters to tune the motor and drive for optimal performance.
T1-00 Motor Selection 1/2
1: 1st Motor - E1 to E2
2: 2nd Motor - E3 to E4 (this selection is not displayed if motor 2 has
not been selected)
T1-01 Auto-Tuning Mode Selection
0: Rotational Auto-Tuning
2: Stationary Auto-Tuning
3: Rotational Auto-Tuning for V/f control
T1-02 Motor Rated Power Sets the motor rated power in kilowatts (kW).
T1-03 Motor Rated Voltage Sets the motor rated voltage in volts (V).
T1-04 Motor Rated Current Sets the motor rated current in amperes (A).
T1-05 Motor Base Frequency Sets the base frequency of the motor in Hertz (Hz).
T1-06 Number of Motor Poles Sets the number of motor poles.
T1-07 Motor Base Speed Sets the base speed of the motor in revolutions per minute r/min (RPM).
T1-11 Motor Iron Loss Provides the iron loss for determining the Energy Saving coefficient.
U1: Operation Status Monitors
Use U1 monitors to display the operation status of the drive.
U1-01 Frequency Reference Monitors the frequency reference.
U1-02 Output Frequency Displays the output frequency.
U1-03 Output Current Displays the output current.
U1-04 Control Mode Refer to V1000 Technical Manual for details.
U1-05 Motor Speed
Displays the motor speed feedback.
Display units are determined by o1-03.
U1-06 Output Voltage Reference Displays the output voltage.
U1-07 DC Bus Voltage Displays the DC bus voltage.
U1-08 Output Power Displays the output voltage (this value is determined internally).
U1-09 Torque Reference
Monitor of internal torque reference value for Open Loop Vector
(OLV) control
B.1 Parameter Table
YASKAWA ELECTRIC TOEP C710606 47A YASKAWA AC Drive – V1000 Quick Start Guide
197
B
Parameter List
