YASKAWA V1000 User Manual

CIMR - V U 2 A 0001 F A A
Drive
V1000
Series
No.
Customized
Specifications
A Standard model
Design
Revision
Order
No.
Region
Code
A Japan
No. Voltage Class
B
1-phase, 200-240 Vac
3-phase, 380-480 Vac
3-phase, 200-240 Vac
2
4
B China
C Europe
T Asia
U USA
<1> Refer to manual TOBPC71060635 for more information on these models.
<2> Refer to manual TOBPC71060621 for more information on these models.
<3> Drives with these specifications do not guarantee complete protection for the specified environmental condition.
No.
Environmental
Specification <3>
A
M
N
S
Standard
Humidity- and
dust-resistant
Oil-resistant
Vibration-resistant
No.
Enclosure Type
IP00/Open-Chassis
B
A
IP20/Open-Chassis
F IP20/NEMA Type 1
J
IP20/Finless <2>
L IP00/Finless <2>
NEMA 4X/IP66 <1>G
n
Single-Phase 200 V
Normal Duty Heavy Duty
No.
Max. Motor
Capacity kW
Rated Output
Current A
No.
Max. Motor
Capacity kW
Rated Output
Current A
0001 0.2 1.2 0001 0.1 0.8
0002 0.4 1.9 0002 0.2 1.6
0003 0.75 3.3 0003 0.4 3.0
0006 1.1 6.0 0006 0.75 5.0
0010 2.2 9.6 0010 1.5 8.0
0012 3.0 12.0 0012 2.2 11.0
– – – 0018 3.7 17.5
Note:
CIMR-VoBA0018 is available with a Heavy Duty rating only.
1.1 Model Number and Nameplate Check
YASKAWA ELECTRIC TOEP C710606 47A YASKAWA AC Drive – V1000 Quick Start Guide
29
1
Receiving

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
