YASKAWA V1000 User Manual

n
Three-Phase 200 V
Normal Duty Heavy Duty
No.
Max Motor
Capacity kW
Rated Output
Current A
No.
Max Motor
Capacity kW
Rated Output
Current A
0001 0.2 1.2 0001 0.1 0.8
0002 0.4 1.9 0002 0.2 1.6
0004 0.75 3.5 0004 0.4 3.0
0006 1.1 6.0 0006 0.75 5.0
0010 2.2 9.6 0010 1.5 8.0
0012 3.0 12.0 0012 2.2 11.0
0020 5.5 19.6 0020 3.7 17.5
0030 7.5 30.0 0030 5.5 25.0
0040 11 40.0 0040 7.5 33.0
0056 15 56.0 0056 11 47.0
0069 18.5 69.0 0069 15 60.0
n
Three-Phase 400 V
Normal Duty Heavy Duty
No.
Max. Motor
Capacity kW
Rated Output
Current A
No.
Max. Motor
Capacity kW
Rated Output
Current A
0001 0.4 1.2 0001 0.2 1.2
0002 0.75 2.1 0002 0.4 1.8
0004 1.5 4.1 0004 0.75 3.4
0005 2.2 5.4 0005 1.5 4.8
0007 3.0 6.9 0007 2.2 5.5
0009 3.7 8.8 0009 3.0 7.2
0011 5.5 11.1 0011 3.7 9.2
0018 7.5 17.5 0018 5.5 14.8
0023 11 23.0 0023 7.5 18.0
0031 15 31.0 0031 11 24.0
0038 18.5 38.0 0038 15 31.0
1.1 Model Number and Nameplate Check
30
YASKAWA ELECTRIC TOEP C710606 47A YASKAWA AC Drive – V1000 Quick Start Guide

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
