YASKAWA V1000 - Page 62

Model
CIMR-
Vo2A
Terminal
Recomm.
Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw
Size
Tightening
Torque
N•m (lb.in.)
0040
R/L1, S/L2, T/L3 6 10 to 6
M4
2.1 to 2.3
(18.6 to 20.4)
U/T1, V/T2, W/T3 8 10 to 6
–, +1, +2 – 10 to 6
B1, B2 – 14 to 10
6 10 to 6 M5
2 to 2.5
(17.7 to 22.1)
0056
R/L1, S/L2, T/L3 4 6 to 4
M6
5.4 to 6.0
(48.7 to 53.1)
U/T1, V/T2, W/T3 4 6 to 4
–, +1, +2 – 6 to 4
B1, B2 – 10 to 6 M5
2.7 to 3.0
(23.9 to 26.6)
6 8 to 4 M6
4 to 6
(35.4 to 53.1)
0069
R/L1, S/L2, T/L3 3 8 to 2
M8
9.9 to 11
(87.6 to 97.4)
U/T1, V/T2, W/T3 3 8 to 2
–, +1, +2 – 8 to 2
B1, B2 – 8 to 6 M5
2.7 to 3.0
(23.9 to 26.6)
6 6 to 4 M6
4 to 6
(35.4 to 53.1)
n
Three-Phase 400 V Class
Table 3.4 Wire Gauge and Torque Specifications
Model
CIMR-
Vo4A
Terminal
Recomm.
Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw
Size
Tightening
Torque
N•m (lb.in.)
0001
0002
0004
R/L1, S/L2, T/L3 14 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
–, +1, +2 – 14 to 10
B1, B2 – 14 to 10
14 14 to 10
0005
0007
0009
R/L1, S/L2, T/L3 14 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
–, +1, +2 – 14 to 10
B1, B2 – 14 to 10
10 14 to 10
3.4 Main Circuit Wiring
62
YASKAWA ELECTRIC TOEP C710606 47A YASKAWA AC Drive – V1000 Quick Start Guide
