YASKAWA V1000 - Page 63

Model
CIMR-
Vo4A
Terminal
Recomm.
Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw
Size
Tightening
Torque
N•m (lb.in.)
0011
R/L1, S/L2, T/L3 12 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
–, +1, +2 – 14 to 10
B1, B2 – 14 to 10
10 14 to 10
0018
R/L1, S/L2, T/L3 10 14 to 6
M4
2.1 to 2.3
(18.6 to 20.4)
U/T1, V/T2, W/T3 10 14 to 6
–, +1, +2 – 14 to 6
B1, B2 – 14 to 10
8 14 to 6 M5
2 to 2.5
(17.7 to 22.1)
0023
R/L1, S/L2, T/L3 10 10 to 6
M4
2.1 to 2.3
(18.6 to 20.4)
U/T1, V/T2, W/T3 10 10 to 6
–, +1, +2 – 10 to 6
B1, B2 – 14 to 10
8 10 to 6 M5
2 to 2.5
(17.7 to 22.1)
0031
R/L1, S/L2, T/L3 8 10 to 6
M5
2.7 to 3.0
(23.9 to 26.6)
U/T1, V/T2, W/T3 8 10 to 6
–, +1, +2 – 10 to 6
B1, B2 – 14 to 10
6 10 to 6 M6
4 to 6
(35.4 to 53.1)
0038
R/L1, S/L2, T/L3 6 10 to 6
M5
2.7 to 3.0
(23.9 to 26.6)
U/T1, V/T2, W/T3 8 10 to 6
–, +1, +2 – 10 to 6
B1, B2 – 10 to 8
6 10 to 6 M6
4 to 6
(35.4 to 53.1)
3.4 Main Circuit Wiring
YASKAWA ELECTRIC TOEP C710606 47A YASKAWA AC Drive – V1000 Quick Start Guide
63
3
Electrical Installation
