Yealink VC110 User Manual

User Guide for Yealink VC110 Video Conferencing Endpoint
138
To mute the VCM30 during a call:
1. Tap to mute the call.
The mute indicator LED illuminates solid red. And the mute icon appears on the local
video image.
To un-mute the VCM30 during a call:
1. Tap again to un-mute the call.
The mute indicator LED illuminates solid green. And the mute icon disappears from
the local video image.
Viewing VCM30 Information
When the VCM30 is connected to the Audio In port of cable hub, you can view VCM30 status via
the remote control or web user interface.
Available information of VCM30 includes:
 Status
 Model
 Hardware
 Serial Number
To view the VCM30 information via the remote control:
1. Press (Menu soft key) to enter main menu.
2. Press or to select the Status menu.
3. Press or to scroll to select the Wired Micpod, and then press .

Yealink VC110 Specifications

General

Digital zoom	4 x
Focus adjustment	Auto
Video codecs	H.264, H.263
Maximum frame rate	30 fps
Supported video modes	720p, 1080p
Video formats supported	H.263, H.264
Supported graphics resolutions	352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711a, G.722, G.722.1, G.722.1C
Line-in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pan range	-100 - 100 °
Tilt angle range	-30 - 30 °
Security algorithms	128-bit AES, HTTPS, SRTP, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols	TCP/IP (IPv4), DHCP/ stastic IP, HTTP/ HTTPS, SRTP/TLS, IEEE802.1X, LLDP-MED, VLAN
Current	2 A
Power consumption (max)	30 W
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	151.5 mm
Width	234.6 mm
Height	161 mm
Package depth	318 mm
Package width	432 mm
Package height	274 mm
Package weight	5900 g
