Yealink VC110 User Manual

Customizing the VC110 Video Conferencing Endpoint
63
8. Select the desired contact bandwidth from the pull-down list of Bandwidth.
The default contact bandwidth is Auto. The endpoint will select the appropriate bandwidth
automatically.
9. Press (Save soft key) to save the local contact.
Note
You can also add contacts via the web user interface at the path Directory->Local Directory.
Placing Calls to Contacts
You can place calls to local contacts via the remote control, video conferencing phone or web
user interface. If you log into the Yealink Cloud platform, you can also place calls to Cloud
contacts.
To place a call to a local contact via the remote control:
1. Press (Call soft key).
2. Press or to select the Directory menu.
3. Select the desired contact type from the pull-down list of the All Contacts first.
4. Press or to select the desired local contact.
5. Press .
- If only one number is stored for the contact, the contact number will be dialed out
directly.
If the contact already exists in the directory, the display device will prompt “Contact already
exists!”.

Yealink VC110 Specifications

General

Digital zoom	4 x
Focus adjustment	Auto
Video codecs	H.264, H.263
Maximum frame rate	30 fps
Supported video modes	720p, 1080p
Video formats supported	H.263, H.264
Supported graphics resolutions	352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711a, G.722, G.722.1, G.722.1C
Line-in	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pan range	-100 - 100 °
Tilt angle range	-30 - 30 °
Security algorithms	128-bit AES, HTTPS, SRTP, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols	TCP/IP (IPv4), DHCP/ stastic IP, HTTP/ HTTPS, SRTP/TLS, IEEE802.1X, LLDP-MED, VLAN
Current	2 A
Power consumption (max)	30 W
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	151.5 mm
Width	234.6 mm
Height	161 mm
Package depth	318 mm
Package width	432 mm
Package height	274 mm
Package weight	5900 g
