Appendix
App.3-1
IM CA150E
1
2
3
4
5
6
7
8
9
10
11
12
App
Appendix 3
Installing Ferrite Core
CAUTION
T
o comply with the EMC Directive, install the included ferrite cores on
the lead cables as shown below (in a three-wire output system,
the third source lead cable [black] must also be equipped with a ferrite core).
50mm
50mm
Ferrite core
A1
193MN
Measurement lead cables
RD031
Source lead cables
98020
132
134
