5-2
IM CA150E
5.1 Connecting the Measurement T
erminals
5.1
Connecting the Measurement T
erminals
Measurement
indication
Function
selection
Operation on
measurement side
Measurement lead cables
(RD031)
Black
Red
Measurement input
terminals
This shows the lead cable connections
for when DCV
, &ohm&, TC, RTD, or
FREQ is selected with FUNCTION. For
the connections when DCA
or 24V
LOOP (DCA) is selected, refer to the
next page.
