1. Product Outline
1.1 Product Outline
Generation (SOURCE)
Function Range
DC Voltage (DCV) 100 mV, 1 V, 10 V, 30 V
DC Current (DCA) 20 mA, 20 mA SINK, 4-20 mA
Resistance (Ω) 500 Ω, 5 kΩ, 50 kΩ
Thermocouple (TC) K, E, J, T, N, L, U, R, S, B
Resistance temperature detector (RTD) Pt100, JPt100
Frequency and pulse (PULSE) CPM, 100 Hz, 1000 Hz, 10 kHz,
50 kHz
Measurement (MEASURE)
Function Range
DC Voltage (DCV) 35 V, 5 V, 500 mV
DC Current (DCA) 100 mA, 20 mA
Resistance (Ω) 50 kΩ, 5 kΩ, 500 Ω
Thermocouple (TC) K, E, J, T, N, L, U, R, S, B
Resistance temperature detector (RTD) Pt100, JPt100
Frequency and pulse (FREQ) 100 Hz, 1000 Hz, 10 kHz, CPM, CPH
24V LOOP (DCA)
Other
Divided output (n/m) function
Sweep output functions
Step sweep function
Linear sweep function
Program sweep function
Temperature monitor function
Averaging (measurement)
