IM CA150E
7. Setting Mode ......................................7-1
7.1 Source ..........................................7-2
7.2 Measure.........................................7-3
7.3 Conguration .....................................7-4
8. Communication Function ............................8-1
8.1 Cable Connection and Interface Specications...........8-1
8.2 Communication Command List .......................8-2
8.3 Detailed Description of Commands ....................8-4
8.4 Error Code List ..................................8-14
8.5 Table of Valid Communication Commands .............8-15
8.6 Status Byte Format ...............................8-17
8.7 Output Format of Printer Mode ......................8-18
9. Calibration Mode ...................................9-1
9.1 Calibration of Source Functions (Adjustment) ............9-2
9.2 Calibration of Measurement Functions
(Adjustment) .....................................9-5
9.3 Verication after Calibration..........................9-8
9.4 Calibration of Temperature Ranges....................9-8
10. Troubleshooting ................................10-1
10.1 Troubleshooting Checklist ..........................10-1
11. Specications ..................................11-1
12. Sales in Each Country or Region ..................12-1
12.1 Disposing the Product .............................12-1
12.2 How to Replace and Dispose the Batteries.............12-2
12.3 Authorized Representative in the EEA ................12-2
12.4 For the Pollution Control of Electronic and
Electrical Products of the People's
Republic of China ................................12-3
Appendix 1 Using a Cold Junction Compensator ..........App.1-1
Appendix 2 Block Diagram.............................App.2-1
Appendix 3 Installing Ferrite Core.......................App.3-1
