• Decimal Point (Decimal Point)
When you save data in ASCII format, you can choose how to separate the data.
• Point (Point): The decimal point is a period, and the separator is a comma.
• Comma (Comma): The decimal point is a comma, and the separator is a period.
• Saving Sub Channel Data (Sub Channel)
When you save data in ASCII format, you can choose how to interpolate the data of 16-CH voltage input
module or 16-CH temperature/voltage input module sub channels.
• Supplement (Supplement): Blank spaces are filled with repetitions of the same data so that the sub
channels have the same amount of data as an ordinary channel.
• Space (Space): Spaces are left where there is no data.
Notes about Using the 16-CH Voltage Input Module (720220),
Notes about Using the 16-CH Temperature/Voltage Input Module (720221)
• If you change the extension of the saved data file, by using a PC or some other device, the DL850E/
DL850EV will no longer be able to load it.
• Up to 1000 files and folders can be displayed in the file list. If there are more than a total of 1000 files and
folders in a given folder, the file list for that folder will display only 1000 files and folders. There is no way to
set which files and folders are displayed.
• Math waveforms are not saved if they are shorter than 10 div
.
Data Format for Saving Multiple Records
The DL850E/DL850EV saves data that contains multiple records, such as history waveforms, in the following
data format.
ASCII format: CR+LF is inserted between records.
<Header>
CH1 data 1-1, CH2 data 1-1, ..., [CR+LF]
CH1 data 1-2, CH2 data 1-2, ..., [CR+LF]
CH1 data 1-m, CH2 data 1-m, ..., [CR+LF]
[CR+LF]
CH1 data 2-1, CH2 data 2-1, ..., [CR+LF]
CH1 data 2-2, CH2 data 2-2, ..., [CR+LF]
CH1 data 2-n, CH2 data 2-n, ..., [CR+LF]
[CR+LF]
One history record
Float format: Data is saved separately by channel.
Measured data for CH1 on record 1
Measured data for CH1 on record 2
Measured data for CH1 on record N
Measured data for CH2 on record 1
Measured data for CH2 on record 2
Measured data for CH2 on record N
