YOKOGAWA ScopeCorder DL850E

To Next Page

To Previous Page

App-23

IM DL850E-01EN

Appendix

Appendix 6 List of Preset Settings of the Frequency Module

Logic 5V

Setup Item Setting

V Range ±10 V

Coupling DC

Probe Yes

Bandwidth Yes

Threshold 2.5 V

Hys Yes

Slope Yes

Chattering Suppression Yes

Pull Up No

Logic 3V

Setup Item Setting

V Range ±5 V (Probe = 1:1)

±10 V (Probe = 10:1)

Coupling DC

Probe Yes

Bandwidth Yes

Threshold 1.5 V

Hys Yes

Slope Yes

Chattering Suppression Yes

Pull Up No

Logic 12V

Setup Item Setting

V Range ±20 V

Coupling DC

Probe Yes

Bandwidth Yes

Threshold 6 V

Hys Yes

Slope Yes

Chattering Suppression Yes

Pull Up No

Logic 24V

Setup Item Setting

V Range ±50 V

Coupling DC

Probe Yes

Bandwidth Yes

Threshold 12 V

Hys Yes

Slope Yes

Chattering Suppression Yes

Pull Up No
