App-24
IM DL850E-01EN
Appendix
Pull-up 5V
Setup Item Setting
V Range ±10 V
Coupling DC
Probe 1:1
Bandwidth Yes
2
Threshold 2.5 V
Hys Yes
3
Slope Yes
4
Chattering Suppression Yes
5
Pull Up Yes
6
ZeroCross
Setup Item Setting
V Range Yes
7
Coupling AC
Probe Yes
1
Bandwidth Yes
2
Threshold 0 V
Hys Yes
3
Slope Rising
Chattering Suppression Yes
5
Pull Up No
AC100V
Setup Item Setting
V Range ±200 V
Coupling AC
Probe 10:1
Bandwidth Yes
2
(Full cannot be
selected)
Threshold 0 V
Hys Yes
3
Slope Rising
Chattering Suppression Yes
5
Pull Up No
AC200V
Setup Item Setting
V Range ±500 V
Coupling AC
Probe 10:1
Bandwidth Yes
2
(Full cannot be
selected)
Threshold 0 V
Hys Yes
3
Slope Rising
Chattering Suppression Yes
5
Pull Up No
EM Pickup
Setup Item Setting
V Range ±1 V
Coupling DC
Probe 1:1
Bandwidth Yes
2
Threshold 0 V
Hys Yes
3
Slope Rising
Chattering Suppression Yes
5
Pull Up No
