App-25
IM DL850E-01EN
Appendix
User
Setup Item Setting
V Range Yes
7
Coupling Yes
8
Probe Yes
1
Bandwidth Yes
2
Threshold Yes
9
Hys Yes
3
Slope Yes
4
Chattering Suppression Yes
5
Pull Up No
When you select a preset, the setup items are automatically set to the values in the table. The meaning of Yes
and No in the table is as follows:
Yes: The setting can be configured.
No: The setting cannot be configured (it does not appear on the menu).
1
Set the probe type to 1:1 or 10:1.
2 Set the bandwidth limit to 100 Hz, 1 kHz, 10 kHz, 100 kHz, or Full. You cannot select full for
AC100V or
AC200V.
3 Set the hysteresis to ±1%, ±2.5%, or ±5%.
4 Set the slope to rising or falling.
5 Set the chattering elimination value to a value from 0 ms to 1000 ms.
6 Enable or disable the pull-up. This setting is available only for Pull-up 5V.
7 Voltage ranges:
When probe = 1:1, select ±1 V, ±2 V, ±5 V, ±10 V, ±20 V, or ±50 V.
When probe = 10:1, select ±10 V, ±20 V, ±50 V, ±100 V, ±200 V, or ±500 V.
8 Set the coupling to DC or AC.
9 Set the threshold level to a value within the specified voltage range.
