YOKOGAWA UM33A User Manual

17-10
IM 05P03D21-01EN
OutputSettingMenu(Menu:OUT)
Parameter
symbol
Name
Display
level
Settingrange Initial value
RTS
Retransmission
output type of RET
EASY
OFF: Disable
PV1: PV
LPS: 15 V DC loop power supply
PV1
RTH
Maximum value
of retransmission
output scale of RET
STD
When RTS = PV1
RTL + 1 digit to 30000
-19999 to RTH - 1 digit
Decimal point position:
When RTS=PV1, decimal point
position is same as that of PV
input.
100 % of PV
input range
RTL
Minimum value
of retransmission
output scale of RET
STD
0 % of PV
input range
RET.H
100% segmental
point of RET current
output
PRO
-100.0 to 200.0%
100.0%
RET.L
0% segmental point
of RET current
output
PRO 0.0%
RET.A
RET current output
range
STD
4-20: 4 to 20 mA
0-20: 0 to 20 mA
20-4: 20 to 4 mA
20-0: 20 to 0 mA
4-20
RS-485CommunicationSettingMenu(Menu:R485)(E1terminalarea)
Parameter
symbol
Name
Display
level
Settingrange Initial value
PSL Protocol selection EASY
PCL: PC link communication
PCLSM: PC link communication
(with checksum)
LADR: Ladder communication
MBASC: Modbus (ASCII)
MBRTU: Modbus (RTU)
MBRTU
BPS Baud rate EASY
600: 600 bps
1200: 1200 bps
2400: 2400 bps
4800: 4800 bps
9600: 9600 bps
19200: 19.2k bps
38400: 38.4k bps
19200
PRI Parity EASY
NONE: None
EVEN: Even
ODD: Odd
EVEN
STP Stop bit EASY 1: 1 bit, 2: 2 bits 1
DLN Data length EASY 7: 7 bits, 8: 8 bits 8
ADR Address EASY 1 to 99 1
RP.T
Minimum response
time
PRO 0 to 10 (x10ms) 0
17.2ListofParameters
